Product Overview

The Asus ROG Strix B860-F Gaming WiFi is an ATX motherboard built on the Intel B860 chipset for LGA 1851 processors, covering the Core Ultra (Series 2, Arrow Lake) range including K and KF models. It has four DDR5 slots supporting up to 256 GB at up to DDR5-9066 (OC), a PCIe 5.0 x16 slot and four M.2 slots, with the first M.2 slot running PCIe 5.0.

This board suits a modern Intel gaming build where fast storage and strong connectivity matter. Networking comes from Intel 2.5 Gb Ethernet, Wi-Fi 7 and Bluetooth 5.4, while the rear panel adds Thunderbolt 4, a USB 3.2 Gen 2×2 Type-C port, HDMI and DisplayPort. It also has ROG SupremeFX 7.1 audio (ALC4080), Aura Sync lighting support, seven 4-pin PWM fan headers and three addressable RGB headers. A BIOS update may be needed for the newest processors.

Specification

• Manufacturer: Asus
• Model: ROG Strix B860-F Gaming WiFi
• MPN: 90MB1JG0-M0EAY0
• EAN: 47113878069510
• CPU socket: LGA 1851 (Socket V1)
• Chipset: Intel B860
• Form factor: ATX
• Supported processors: Intel Core Ultra 3/5/7/9 (Series 2, Arrow Lake)
• Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, up to DDR5-9066 (OC), non-ECC
• Expansion slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 lanes)
• M.2 slots: 4x M.2 (M key), 1x PCIe 5.0 and 3x PCIe 4.0, 42-110 mm
• SATA: 4x SATA III, RAID 0/1/5/10
• Networking: Intel 2.5 Gb Ethernet, Wi-Fi 7 (802.11be), Bluetooth 5.4
• Rear USB: 1x USB-C 3.2 Gen 2×2 (20 Gbps), 1x USB-A 3.2 Gen 2, 6x USB-A 3.2 Gen 1
• Video outputs: 1x Thunderbolt 4, 1x HDMI, 1x DisplayPort (CPU with integrated graphics required)
• Audio: ROG SupremeFX 7.1 (Realtek ALC4080)
• Fan and RGB headers: 7x 4-pin PWM fan, 3x addressable RGB, Aura Sync
• Dimensions (W x D x H): 305 x 244 x 50 mm
• Weight: 1.51 kg
