Product Overview

The Asus PRO WS W880-ACE SE is an ATX workstation motherboard built on the Intel W880 chipset for LGA 1851 processors, including the Intel Core Ultra (Series 2) range. It stands out with a Thunderbolt 4 port, dual Intel 2.5 Gb Ethernet plus a dedicated Realtek 1 Gb port for the AST2600 BMC, and four M.2 slots, one of which runs at PCIe 5.0.

The board suits workstation builds that need remote management, fast storage and plenty of expansion. It offers four DDR5 slots for up to 256 GB at speeds up to DDR5-9066, support for RAID 0, 1, 5 and 10 across four SATA III ports, and a Slim-SAS connector. Asus describes it as engineered for dual graphics cards, with a chipset heatsink and active fan, and ASUS Control Center Express software is bundled.

Specification

• Manufacturer: Asus
• Model: PRO WS W880-ACE SE
• MPN: 90MB1KV0-M0EAY0
• EAN: 4711387994221
• CPU socket: LGA 1851 (Intel Core Ultra Series 2)
• Chipset: Intel W880
• Form factor: ATX (305 x 244 mm)
• Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, up to DDR5-9066, non-ECC
• Expansion slots: 2x PCIe 5.0 x16 and 1x PCIe 4.0 x16 (3 slots in total)
• M.2 slots: 4x M.2 (M key, up to 2280), 1x PCIe 5.0 and 3x PCIe 4.0
• SATA: 4x SATA III, 1x Slim-SAS (SFF-8643)
• RAID: 0, 1, 5, 10
• LAN: 2x Intel 2.5 Gb Ethernet, 1x Realtek 1 Gb Ethernet (dedicated to AST2600)
• Thunderbolt: 1x Thunderbolt 4 (USB Type-C), DisplayPort and Thunderbolt support
• Rear USB: 1x USB-C 20 Gbit/s, 6x USB-A 10 Gbit/s, 1x USB4
• Video outputs: 1x HDMI, 1x VGA (integrated graphics of the CPU required for HDMI)
• Audio: Realtek ALC1220P, 7.1 channels
• Power connectors: 24-pin ATX, 2x 8-pin EPS
• BIOS: 256 Mbit UEFI AMI
• Wi-Fi: No
