Name: ASRock B760M-HDV/M.2 WHITE Intel B760 LGA 1700 DDR5 Micro ATX Motherboard
Brand: Asrock
SKU: 100017518
Price: 102.16 EUR
Availability: InStock

ASRock B760M-HDV/M.2 WHITE Intel B760 LGA 1700 DDR5 Micro ATX Motherboard

€102.16

Delivery: 7-12 business days
ASRock B760M-HDV/M.2 WHITE Intel B760 LGA 1700 DDR5 Micro ATX Motherboard

White PCB and design for light-themed builds
Two DDR5 slots, up to 96 GB, DDR5-7200+ supported
Two M.2 sockets plus four SATA ports
2.5 GbE LAN and PCIe 4.0 x16 slot

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100017518 Category: Intel Motherboards Tags: Asrock,, B760M-HDV,, INTEL, motherboard, Brand: Asrock

Description
Additional information

✅

Product Overview

The ASRock B760M-HDV/M.2 WHITE is a white Micro ATX motherboard built on the Intel B760 chipset for LGA 1700 processors. It supports 12th and 13th generation Intel CPUs and has two DDR5 DIMM slots running in dual channel for up to 96 GB of memory, with support up to DDR5-7200+. Storage comes from two M.2 sockets and four SATA ports, and networking is handled by a 2.5 GbE LAN port.

This board suits compact and mid-range gaming or home PC builds that use a white colour scheme. The rear I/O offers HDMI, DisplayPort, Mini DisplayPort and VGA outputs for CPUs with integrated graphics, plus one USB-C and three USB-A ports at 5 Gbit/s. There is a PCIe 4.0 x16 slot for a graphics card, two PCIe 4.0 x1 slots, and RGB and addressable RGB headers. A BIOS update may be needed for the newest processors.

Specification

Manufacturer: Asrock
Model: B760M-HDV/M.2 WHITE
MPN: 90-MXBMJ0-A0UAYZ
EAN: 47104839434850
Socket: LGA 1700
Chipset: Intel B760
Form factor: Micro ATX (244 x 244 mm)
Memory: 2x DDR5 DIMM, dual channel, up to 96 GB
Supported memory speeds: DDR5-7200+ / 5200 / 4800 / 4400
Expansion slots: 1x PCIe 4.0 x16, 2x PCIe 4.0 x1
M.2 slots: 2x M.2 (Key M, PCIe, 60-80 mm) plus 1x M.2 for WLAN
SATA ports: 4x SATA 3
LAN: 2.5 GbE (Dragon RTL8125BG)
Audio: Realtek ALC887/897, 8-channel
Rear USB: 1x USB-C 3.2 Gen 1, 3x USB-A 3.2 Gen 1, 2x USB-A 2.0
Video outputs: HDMI, DisplayPort, Mini DisplayPort, VGA
Fan headers: 4x 4-pin PWM
RGB headers: 1x RGB LED, 3x addressable RGB LED
Power connectors: 24-pin ATX + 8-pin ATX12V
Colour: White

return to the shop
see our fanpage

delivery time 7-12 business days

Weight	1.2 kg
