Gigabyte B840M AORUS ELITE WIFI6E AM5 Micro ATX Motherboard, DDR5, Wi-Fi 6E, 2.5GbE

€188.57

Delivery: 7-12 business days
Gigabyte B840M AORUS ELITE WIFI6E AM5 Micro ATX Motherboard, DDR5, Wi-Fi 6E, 2.5GbE

  • Wi-Fi 6E and 2.5GbE LAN both onboard
  • Two PCIe 4.0 M.2 slots for NVMe SSDs
  • DDR5 up to 8200 MT/s (O.C.), 256 GB max
  • Rear USB-C 10 Gbps plus HDMI 2.1 and DisplayPort 1.4

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100142318 Category: Tags: , , , , Brand:

✅

Product Overview

The Gigabyte B840M AORUS ELITE WIFI6E is a Micro ATX motherboard for Socket AM5, built on the AMD B840 chipset. It supports Ryzen 7000, 8000 and 9000 series processors, four DDR5 slots for up to 256 GB at up to 8200 MT/s (O.C.), two PCIe 4.0 M.2 slots, and Wi-Fi 6E with Bluetooth 5.3. A 2.5 Gigabit Realtek LAN port is included alongside the wireless.

It suits a compact AM5 gaming or general-purpose build where you want fast networking and NVMe storage without stepping up to a larger board. Video outputs (HDMI 2.1 and DisplayPort 1.4) work with Ryzen CPUs that have integrated graphics. Four SATA III ports, a 10 Gbps USB-C port and an EZ M.2 Clip II for tool-free SSD fitting are also included. A BIOS update may be needed for the newest processors.

Specification

  • Manufacturer: GigaByte
  • Model: B840M AORUS ELITE WIFI6E
  • MPN: B840M A ELITE WIFI6E
  • EAN: 4719331867331
  • Socket: AMD AM5
  • Chipset: AMD B840
  • Form factor: Micro ATX
  • Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, up to 8200 MT/s (O.C.)
  • M.2 slots: 2x PCIe 4.0 (up to 80 mm and 110 mm)
  • SATA: 4x SATA III, RAID 0/1/10
  • Expansion slots: 1x PCIe 4.0 x16, 1x PCIe x4
  • Wi-Fi / Bluetooth: Wi-Fi 6E (Realtek RTL8852CE), Bluetooth 5.3
  • LAN: 2.5 Gigabit Ethernet (Realtek RTL8125)
  • Audio: Realtek ALC897, 7.1 channels
  • Rear USB: 1x USB-C 10 Gbps, 1x USB-A 10 Gbps, 2x USB-A 5 Gbps, 4x USB 2.0
  • Video outputs: 1x HDMI 2.1, 1x DisplayPort 1.4
  • Power connectors: 24-pin ATX + 8-pin EPS
  • Dimensions (W x H): 243.84 x 243.84 mm

return to the shop
see our fanpage

delivery time 7-12 business days

Weight 1.5 kg
