Product Overview

The Asus TUF Gaming 1200W Gold is a 1200 W ATX power supply with 80 PLUS Gold certification and up to 92% efficiency. It is fully modular and ATX 3.1 compliant, and it ships with two 16-pin PCIe cables that can deliver up to 600 W each to PCIe Gen 5.0 graphics cards. A single 135 mm fan on dual ball bearings keeps it cool, and Asus says this bearing type lasts up to twice as long as a sleeve bearing.

With 99 A on the +12V rail (1,188 W) and three 8-pin PCIe connectors alongside the two 16-pin ones, this PSU suits high-end gaming builds with a powerful graphics card. The capacitors are rated for 105°C and up to 170,000 hours, and the PCB has a protective conformal coating against moisture, dust and debris. The etched modular cables are flexible for tight spaces, and the unit includes cable ties and a full set of protections (OVP, UVP, OCP, OPP, SCP, OTP).

Specification

• Manufacturer: Asus
• Model: TUF Gaming 1200W Gold
• MPN: 90YE00S0-B0NA00
• EAN: 4711081786252
• Total power: 1200 W
• Efficiency rating: 80 PLUS Gold (up to 92% efficiency)
• ATX standard: ATX 3.1
• Form factor: ATX
• Cabling: Fully modular, etched cables
• +12V output: 99 A / 1,188 W
• PCIe connectors: 3x 8-pin, 2x 16-pin (12+4 pin)
• CPU connectors: 2x 4+4 pin
• Other connectors: 1x 20+4 pin ATX, 5x SATA, 4x Molex
• Cooling: 1x 135 mm fan, dual ball bearing
• Input voltage: 100-240 V, active PFC
• Protections: OVP, UVP, OCP, OPP/OLP, SCP, OTP
• Colour: Black
• Dimensions (W x H x D): 150 x 86 x 150 mm
• Weight: 2.66 kg
• Manufacturer warranty: 10 years
