MSI MPG Z890 Carbon WiFi ATX Motherboard, Intel Z890, LGA 1851, DDR5, Wi-Fi 7

€437.55

Delivery: 7-12 business days
MSI MPG Z890 Carbon WiFi ATX Motherboard, Intel Z890, LGA 1851, DDR5, Wi-Fi 7

  • Five M.2 slots, including one PCIe 5.0
  • DDR5 up to 9200 MT/s (O.C.), 256 GB max
  • Wi-Fi 7, 5 GbE and 2.5 GbE LAN
  • 2x Thunderbolt 4 with DisplayPort output

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100078168 Category: Tags: , , , , Brand:

✅

Product Overview

The MSI MPG Z890 Carbon WiFi is an ATX motherboard built on the Intel Z890 chipset for LGA 1851 Core Ultra (Series 2) processors. It has four DDR5 slots for up to 256 GB of memory, with support for speeds up to 9200 MT/s (O.C.), and five M.2 slots, one of them PCIe 5.0. Networking includes 5 GbE and 2.5 GbE LAN, Wi-Fi 7 and Bluetooth 5.4, plus two Thunderbolt 4 ports.

This board suits a high-end Intel Arrow Lake gaming or content-creation build that needs plenty of fast storage and connectivity. It offers three PCIe x16 slots (two PCIe 5.0, one PCIe 4.0), four SATA ports, 10 USB-A and one USB-C port at the rear, 7.1-channel audio from a Realtek ALC1220P codec, and Mystic Light RGB. An EZ-WiFi antenna, SATA cables and EZ M.2 Clips II are included. A BIOS update may be needed for the newest processors.

Specification

  • Manufacturer: MSI
  • Model: MPG Z890 Carbon WiFi
  • MPN: 7E17-001R
  • EAN: 4711377260794
  • Socket: LGA 1851
  • Chipset: Intel Z890
  • Form factor: ATX
  • Supported processors: Intel Core Ultra 5 / 7 / 9 (Series 2, Arrow Lake)
  • Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB
  • Memory speed: DDR5-5600 to 6400 MT/s, up to 9200 MT/s (O.C.)
  • Expansion slots: 3x PCIe x16 (2x PCIe 5.0, 1x PCIe 4.0; x16 / x8 / x4)
  • M.2 slots: 5x M.2 (M key, 60-110 mm); slot 1 PCIe 5.0, slots 2-4 PCIe 4.0
  • SATA: 4x SATA III, RAID 0/1/5/10
  • LAN: Intel Killer E5000B 5 GbE + Intel I226V 2.5 GbE
  • Wireless: Wi-Fi 7 (Killer BE1750x), Bluetooth 5.4
  • Rear I/O: 2x Thunderbolt 4, 10x USB-A 10 Gbps, 1x USB-C 10 Gbps, 1x HDMI, 2x RJ-45, audio, optical S/PDIF
  • Audio: Realtek ALC1220P, 7.1 channels
  • Fan and RGB headers: 7x 4-pin PWM fan, 1x RGB, 3x ARGB (Mystic Light)
  • Power connectors: 24-pin ATX + 2x 8-pin CPU
  • Dimensions (W x D): 243.8 x 304.8 mm
