Product Overview

The Asus PRO WS W680M-ACE SE is a workstation motherboard built on the Intel W680 chipset for LGA 1700 processors. It has four DDR5 memory slots in dual-channel configuration and two M.2 slots with PCIe 4.0 x4 support. Onboard BMC remote management with a dedicated 1 Gb management port sets it apart from standard consumer boards, alongside three Ethernet ports (2 x Intel 2.5 Gb and 1 x Realtek 1 Gb).

This micro-ATX board suits compact workstation and always-on builds where reliability and remote administration matter. It offers eight SATA ports, a SlimSAS connector and RAID 0, 1, 5 and 10 for storage-heavy setups, plus HDMI, DisplayPort and VGA outputs when paired with a CPU with integrated graphics. Asus describes it as optimised for 24/7 operation, with dedicated heatsinks including for the M.2 slots. Asus Control Center Express software is supported for managing multiple systems.

Specification

• Manufacturer: Asus
• Model: PRO WS W680M-ACE SE
• MPN: 90MB1FA0-M0EAY0
• EAN: 47113872981900
• CPU socket: LGA 1700
• Chipset: Intel W680
• Form factor: Micro-ATX
• Memory: 4 x DDR5 slots, dual-channel, up to 128 GB, ECC supported
• Expansion slots: 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x4, 1 x PCIe 3.0 x1
• M.2 slots: 2 x M.2 (M key, PCIe 4.0 x4), 42-80 mm
• SATA ports: 8 (RAID 0, 1, 5, 10)
• Other storage: 1 x SlimSAS connector
• Networking: 2 x Intel 2.5 Gb Ethernet, 1 x Realtek 1 Gb Ethernet (BMC management port)
• Remote management: BMC (ASPEED AST2600)
• Video outputs: HDMI 2.1, DisplayPort 1.4, VGA (requires CPU with integrated graphics)
• Rear USB: 1 x USB-C 3.2 Gen 2, 1 x USB-A 3.2 Gen 2, 4 x USB-A 3.2 Gen 1
• Audio: Realtek 7.1 channel HD audio
• Power connectors: 24-pin ATX + 8-pin ATX12V
• BIOS: 256 Mb flash ROM, UEFI AMI BIOS
• Dimensions (W x D): 244 x 244 mm
• Weight: 820 g
