Name: Asus PRIME H610M-A-CSM Intel H610 LGA 1700 Micro-ATX Motherboard, DDR5
Brand: Asus
SKU: 100019987
Price: 130.60 EUR
Availability: InStock

Asus PRIME H610M-A-CSM Intel H610 LGA 1700 Micro-ATX Motherboard, DDR5

€130.60

Delivery: 7-12 business days
Asus PRIME H610M-A-CSM Intel H610 LGA 1700 Micro-ATX Motherboard, DDR5

LGA 1700 board with DDR5-4800 to 5600 support
Two M.2 slots plus four SATA ports
PCIe 4.0 x16 slot for a graphics card
Compact micro-ATX, 244 x 216 mm

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100019987 Category: Intel Motherboards Tags: 12th, Asus,, Gen,, H610M-A, INTEL, motherboard, Brand: Asus

Description
Additional information

✅

Product Overview

The Asus PRIME H610M-A-CSM is a micro-ATX motherboard built on the Intel H610 chipset for LGA 1700 processors. It uses DDR5 memory, with two DIMM slots in dual-channel mode supporting up to 96 GB at speeds from DDR5-4800 to DDR5-5600. Expansion includes a PCIe 4.0 x16 slot, a PCIe 3.0 x1 slot and two M.2 slots, with four SATA connectors for further storage.

This board suits compact, budget-friendly gaming and everyday PCs, especially builds that use a CPU with integrated graphics, as the VGA, HDMI and DisplayPort outputs only work with such processors. Connectivity covers Intel Gigabit LAN, Realtek 7.1-channel audio, four USB 2.0 ports on the rear panel and a TPM header. One RGB header with Aura Sync support and three 4-pin PWM fan headers are included. A BIOS update may be needed to support the newest processors.

Specification

Manufacturer: Asus
Model: PRIME H610M-A-CSM
MPN: 90MB1G20-M0EAYC
EAN: 4711387293935
CPU socket: LGA 1700
Chipset: Intel H610
Form factor: micro-ATX (244 x 216 mm)
Memory: 2x DIMM, DDR5-4800 to DDR5-5600, dual-channel, up to 96 GB, non-ECC
Expansion slots: 1x PCIe 4.0 x16, 1x PCIe 3.0 x1
M.2 slots: 2x M.2 (M key), SATA and PCIe, 42-80 mm
SATA ports: 4x SATA 6Gb/s
Video outputs: 1x VGA, 1x HDMI, 1x DisplayPort (CPU with integrated graphics required)
Rear USB: 4x USB 2.0
Network: Intel Gigabit LAN (RJ-45)
Audio: Realtek 7.1-channel HD Audio
Fan and RGB headers: 3x 4-pin PWM fan, 1x RGB (Aura Sync)
BIOS: 128 Mbit UEFI AMI
Weight: 554 g
