Product Overview

The Gigabyte B650M Gaming Plus WIFI motherboard is a micro ATX board built on the AMD B650 chipset for Socket AM5 processors. It supports Ryzen 7000, 8000 and 9000 series CPUs, has four DDR5 slots for up to 256 GB of memory (up to DDR5-8000 with overclocking), and includes two PCIe 4.0 M.2 slots, a 2.5 GbE LAN port and Wi-Fi 6E with Bluetooth 5.3 onboard.

This board suits compact AM5 gaming builds in a micro ATX case where built-in wireless networking matters. Storage is covered by four SATA III ports and two M.2 slots, with RAID 0, 1 and 10 support. Video outputs are HDMI 2.1 and two DisplayPort 1.4, usable with CPUs that have integrated graphics. One RGB header and two addressable RGB headers are provided. A BIOS update may be needed for the newest processors.

Specification

• Manufacturer: GigaByte
• Model: B650M Gaming Plus WIFI
• MPN: B650M GAMING PLUS WF
• EAN: 47193318622130
• Socket: AMD AM5
• Chipset: AMD B650
• Form factor: micro ATX
• Memory: 4x DDR5 DIMM, dual-channel, max. 256 GB, up to DDR5-8000 (OC), non-ECC
• M.2 slots: 2x M.2 (M key), both PCIe 4.0
• SATA: 4x SATA III, RAID 0/1/10
• Expansion slots: 1x PCIe 4.0 x16, 1x PCIe 3.0 x1
• Networking: Realtek 2.5 GbE LAN, Wi-Fi 6E (RTL8852CE), Bluetooth 5.3
• Video outputs: 1x HDMI 2.1, 2x DisplayPort 1.4
• Rear USB: 1x USB-C 3.2 Gen 1, 3x USB-A 3.2 Gen 1, 2x USB-A 2.0
• Internal USB: 1x USB-C 3.2 Gen 2 (10 Gbit/s) header
• Audio: Realtek codec, 7.1 channels
• Fan headers: 3x 4-pin PWM
• RGB headers: 1x RGB, 2x addressable RGB
• Power connectors: 24-pin ATX + 8-pin EPS
• Dimensions (W x D): 244 mm x 244 mm
