Gigabyte B650M D3HP AM5 Micro ATX Motherboard, DDR5, 2.5GbE, 2x M.2 PCIe 4.0

€135.85

Delivery: 7-12 business days
Gigabyte B650M D3HP AM5 Micro ATX Motherboard, DDR5, 2.5GbE, 2x M.2 PCIe 4.0

  • Socket AM5 for Ryzen 7000, 8000 and 9000 series
  • 4x DDR5 slots, speeds up to 7600 MHz (OC)
  • 2x PCIe 4.0 M.2 slots plus 4x SATA III
  • 2.5GbE LAN and HDMI 2.1 with 2x DisplayPort 1.4

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100015850 Category: Tags: , , , , , Brand:

✅

Product Overview

The Gigabyte B650M D3HP is a micro ATX motherboard built on the AMD B650 chipset for Socket AM5 processors. It supports Ryzen 7000, 8000 and 9000 series CPUs, has four DDR5 slots with memory speeds up to 7600 MHz (OC), and offers two PCIe 4.0 M.2 slots, a PCIe 4.0 x16 slot and 2.5 Gigabit Ethernet on a compact board.

With only one PCIe x16 slot and one PCIe x1 slot, this board suits compact, budget-friendly AM5 builds for gaming or everyday use. Four SATA III ports and two M.2 slots give room for several drives, while HDMI 2.1 and two DisplayPort 1.4 outputs are available when you use a CPU with integrated graphics. Wi-Fi is not included, so wired networking is the way to connect.

Specification

  • Manufacturer: GigaByte
  • Model: B650M D3HP
  • MPN: B650M D3HP
  • EAN: 0889523039083
  • Socket: AMD AM5
  • Chipset: AMD B650
  • Form factor: micro ATX
  • Memory: 4x DDR5 DIMM, dual-channel, non-ECC
  • Memory speed: DDR5-4800 to 7600 (OC)
  • Maximum memory: 192 GB
  • M.2 slots: 2x M.2 (M key), both PCIe 4.0
  • SATA: 4x SATA III, RAID 0/1/10
  • Expansion slots: 1x PCIe 4.0 x16, 1x PCIe 3.0 x1
  • Networking: 2.5 Gigabit Ethernet (Realtek RTL8125), no Wi-Fi
  • Rear USB: 3x USB-A 3.2 Gen 1, 1x USB-C 3.2 Gen 1, 2x USB-A 2.0
  • Video outputs: 1x HDMI 2.1, 2x DisplayPort 1.4
  • Audio: Realtek ALC897, 7.1 channel
  • Dimensions (W x H): 244 x 244 mm

return to the shop
see our fanpage

delivery time 7-12 business days

Weight 1.5 kg
