Product Overview

The Gigabyte B550 Eagle WiFi 6 is an ATX motherboard for Socket AM4, built on the AMD B550 chipset. It stands out with built-in Wi-Fi 6 (Realtek RTL8851BE) and Bluetooth 5.3, so a wireless build needs no extra card, plus a PCIe 4.0 x16 slot and two M.2 slots, the first running at PCIe 4.0. Four DIMM slots take up to 128 GB of dual-channel DDR4, with ECC and non-ECC support.

This board suits a mid-range AM4 gaming or general-purpose PC based on a Ryzen 3000, 4000 or 5000 series processor. Storage options are generous, with two M.2 slots (up to 22110 length) and four SATA III ports, and RAID 0, 1 and 10 are available. Cooling and lighting are covered by five 4-pin PWM fan headers and RGB and addressable RGB headers. An integrated-graphics CPU can use the HDMI 2.1 output. A BIOS update may be needed for the newest processors.

Specification

• Manufacturer: GigaByte
• Model: B550 Eagle WiFi 6
• MPN: B550 EAGLE WIFI6
• EAN: 47193318684060
• Socket: AMD AM4
• Chipset: AMD B550
• Form factor: ATX
• Compatible processors: AMD Ryzen 3000, 4000 and 5000 series
• Memory: 4x DIMM DDR4, dual-channel, up to 128 GB, ECC and non-ECC
• Memory speeds: DDR4-2133 to 3200 MHz, up to 5200 MHz (O.C.)
• Expansion slots: 1x PCIe 4.0 x16, 4x PCIe 3.0 x1
• M.2 slots: 2x M key, up to 22110; 1st PCIe 4.0, 2nd PCIe 3.0
• SATA: 4x SATA III, RAID 0, 1, 10
• Wireless: Wi-Fi 6 (802.11ax), Bluetooth 5.3
• LAN: Gigabit Ethernet (Realtek RTL8111H)
• Rear USB: 1x USB-C 3.2 Gen 1, 1x USB-A 3.2 Gen 2, 1x USB-A 3.2 Gen 1, 4x USB 2.0
• Video output: 1x HDMI 2.1 (CPU with integrated graphics required)
• Audio: Realtek ALC897, 7.1 channels
• Fan headers: 5x 4-pin PWM
• RGB headers: 2x RGB, 2x addressable RGB
• Weight: 1.7 kg
