Product Overview

The Seasonic CORE GC-650 is a 650 W ATX power supply that meets the ATX 3.1 standard and carries 80 PLUS Gold efficiency certification. It delivers 648 W on the single +12 V rail (54 A) and comes with two 6+2-pin graphics connectors, two 4+4-pin 12V CPU connectors and three SATA connectors, in a compact 140 mm deep housing.

With a 120 mm HDB fan controlled by Smart and Silent Fan Control (S2FC), the CORE GC series is aimed at gamers and PC builders who want a compact, efficient unit for a mainstream system. Active PFC, a 100-240 V input range and a full set of protections (OCP, OVP, UVP, OPP, SCP, OTP) round out the specification. The finish is black with a scratch-resistant surface.

Specification

• Manufacturer: Seasonic
• Model: CORE GC-650
• MPN: SRP-CGC651-A5A32SF
• EAN: 4711173879091
• Wattage: 650 W
• Efficiency Rating: 80 PLUS Gold
• Standards: ATX12V 2.3, ATX12V 3.1, EPS, PCIe 5.1
• Form Factor: ATX
• +12 V Output: 648 W (54 A, single rail)
• +3.3 V / +5 V Combined: 100 W
• Connectors: 1x 24-pin ATX, 2x 4+4-pin 12V, 2x 6+2-pin PCIe, 3x 15-pin SATA
• Fan: 1x 120 mm HDB, temperature-controlled (S2FC)
• Power Factor Correction: Active PFC
• Input Voltage: 100-240 V
• Protections: OCP, OVP, UVP, OLP/OPP, SCP, OTP
• Colour: Black
• Dimensions (W x H x D): 150 x 86 x 140 mm
