Name: Asus PRO H810M-C-CSM Intel H810 LGA 1851 DDR5 Micro ATX Motherboard
Brand: Asus
SKU: 100106794
Price: 149.01 EUR
Availability: InStock

Asus PRO H810M-C-CSM Intel H810 LGA 1851 DDR5 Micro ATX Motherboard

€149.01

Delivery: 7-12 business days
Asus PRO H810M-C-CSM Intel H810 LGA 1851 DDR5 Micro ATX Motherboard

LGA 1851 socket for Intel Core Ultra (Series 2) CPUs
2x DDR5 slots, up to 128 GB, speeds up to DDR5-6400
Two PCIe 4.0 M.2 slots plus four SATA III ports
HDMI, DisplayPort, DVI-D and VGA video outputs

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100106794 Category: Intel Motherboards Tags: Asus,, H810, Intel,, motherboard, Brand: Asus

Description
Additional information

✅

Product Overview

The Asus PRO H810M-C-CSM is a micro ATX motherboard for LGA 1851 processors, built on the Intel H810 chipset. It takes Intel Core Ultra (Series 2, Arrow Lake) CPUs and has two DDR5 slots supporting up to 128 GB at speeds up to DDR5-6400. Storage is well covered, with two M.2 slots (PCIe 4.0, up to 2280) and four SATA III ports.

With a PCIe x16 slot, two PCIe x1 slots and a wide spread of video outputs (HDMI, DisplayPort, DVI-D and VGA), it suits compact office, home and general-purpose PC builds. Networking is handled by Intel I219V Gigabit Ethernet, and there are 7.1-channel Realtek audio, a USB-C 3.2 Gen 2 port and a TPM header. A BIOS update may be needed for the newest processors.

Specification

Manufacturer: Asus
Model: PRO H810M-C-CSM
MPN: 90MB1KHP-M0EAYC
EAN: 4711387856512
CPU socket: LGA 1851
Chipset: Intel H810
Form factor: micro ATX
Supported processors: Intel Core Ultra 3/5/7/9 (Series 2, Arrow Lake)
Memory: 2x DDR5 DIMM, dual-channel, up to 128 GB, non-ECC
Memory speeds: DDR5-6400 / 5200 / 4800 / 4400
M.2 slots: 2x M.2 (M key, PCIe 4.0, up to 2280)
SATA: 4x SATA III 6Gb/s
Expansion slots: 1x PCIe x16, 2x PCIe x1
Rear USB: 1x USB-C 3.2 Gen 2, 1x USB-A 3.2 Gen 2, 2x USB-A 3.2 Gen 1, 2x USB 2.0
Video outputs: HDMI, DisplayPort, DVI-D, VGA (requires CPU with integrated graphics)
Networking: Intel I219V Gigabit Ethernet (no Wi-Fi onboard)
Audio: Realtek, 7.1 channels
Dimensions (W x D): 244 x 222 mm

return to the shop
see our fanpage

delivery time 7-12 business days

Weight	1.2 kg
