Product Overview

The Asus PRIME H810M-A-CSM is a micro-ATX motherboard built on the Intel H810 chipset for LGA 1851 processors from the Intel Core Ultra (Series 2) family. It has two DDR5 DIMM slots supporting up to 128 GB at up to 6400 MHz, one PCIe 4.0 x16 slot, two M.2 slots with PCIe 4.0 support and four SATA III ports. Power is delivered through a 6+1+1+1 phase design with discrete MOSFETs.

This board suits compact and budget-conscious Intel Core Ultra builds that need a solid set of ports without paying for a higher-tier chipset. It offers HDMI 2.1 and DisplayPort 1.4 outputs for CPUs with integrated graphics, Intel I219V Gigabit LAN and 7.1-channel audio. The CSM (Corporate Stable Model) version comes with ASUS Control Center Express IT management software. A BIOS update may be needed to support the newest processors.

Specification

• Manufacturer: Asus
• Model: PRIME H810M-A-CSM
• MPN: 90MB1KK0-M0EAYC
• EAN: 47113878446250
• CPU socket: LGA 1851 (Socket V1)
• Chipset: Intel H810
• Supported processors: Intel Core Ultra 3/5/7/9 (Series 2, Arrow Lake)
• Form factor: micro-ATX
• Memory: 2x DDR5 DIMM, dual-channel, up to 128 GB, up to 6400 MHz, non-ECC
• Expansion slots: 1x PCIe 4.0 x16, 1x PCIe 4.0 x1
• M.2 slots: 2x M.2 (M key, 2280, PCIe 4.0), 1x M.2 (E key) for Wi-Fi
• SATA ports: 4x SATA III
• Video outputs: 1x HDMI 2.1, 1x DisplayPort 1.4 (requires CPU with integrated graphics)
• Rear USB: 2x USB-A 3.2 Gen 2 (10 Gbit/s), 4x USB-A 2.0
• LAN: Gigabit Ethernet, Intel I219V
• Audio: 7.1 channels
• Power connectors: 24-pin ATX, 8-pin EPS
• Dimensions (W x D x H): 244 x 222 x 37 mm
• Weight: 534 g
