Sapphire PULSE A620AM AM5 Micro ATX Motherboard, AMD A620, DDR5
- AM5 socket with AMD A620 chipset for Ryzen 7000/8000/9000
- Two DDR5 slots, up to 64 GB, speeds up to 7600 MHz
- PCIe Gen 4.0 M.2 slot plus four SATA ports
- Compact Micro ATX board, 235 x 244 mm
More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.
In stock
✅
Product Overview
The Sapphire PULSE A620AM AM5 motherboard is a Micro ATX board built on the AMD A620 chipset for Ryzen processors on the AM5 socket. It has two DDR5 slots supporting up to 64 GB at speeds up to 7600 MHz, a PCIe x16 slot and M.2 storage support with a PCIe Gen 4.0 slot, plus four SATA ports for additional drives.
With its compact µATX format, this board suits small to mid-sized gaming and general-purpose PC builds based on Ryzen 5, 7 or 9 processors from the 7000, 8000 and 9000 series, including X3D models. Video outputs (HDMI and DisplayPort) work when you use a CPU with integrated graphics. Networking is covered by Realtek Gigabit LAN, audio by a Realtek ALC897 codec. Note that a BIOS update may be required to support the newest processors.
Specification
- Manufacturer: Sapphire
- Model: PULSE A620AM
- MPN: 52118-03-40G
- EAN: 4895106296879
- Socket: AMD AM5
- Chipset: AMD A620
- Form factor: Micro ATX (µATX)
- Memory: 2x DDR5 DIMM, up to 64 GB, dual channel
- Memory speed: DDR5 up to 7600 MHz
- Expansion slots: 1x PCIe x16, 1x PCIe x4
- M.2 storage: 1x M.2 slot, PCIe Gen 4.0
- SATA ports: 4x SATA
- RAID levels: 0, 1, 10
- Rear USB: 2x USB-A 3.2 Gen 1 (5 Gbit/s), 4x USB-A 2.0
- Video outputs: 1x HDMI, 1x DisplayPort (CPU with integrated graphics required)
- LAN: Realtek RTL8111K Gigabit LAN (RJ-45)
- Audio: Realtek ALC897
- Power connectors: ATX 24-pin + 8-pin
- Dimensions (W x H): 235 mm x 244 mm
