Product Overview

The Gigabyte B850 AORUS ELITE-P ICE is a white ATX motherboard for Socket AM5, built on the AMD B850 chipset. It offers four DDR5 slots for up to 256 GB of memory, four M.2 slots including one PCIe 5.0 slot, Wi-Fi 7 with Bluetooth 5.4 and a Realtek 5GbE LAN port, which makes it well equipped for a mid-range AM5 platform.

It suits gaming and general-purpose builds around Ryzen 7000, 8000 and 9000 series processors, including X3D models, especially where a white colour scheme is wanted. With six 4-pin PWM fan headers, four SATA ports and a USB-C 10 Gbit/s port on the rear I/O, it has room for plenty of storage and cooling. Note that a BIOS update may be needed to support the newest processors, and the video outputs only work with a CPU that has integrated graphics.

Specification

• Manufacturer: GigaByte
• Model: B850 AORUS ELITE-P ICE
• MPN: B850 A ELITE-P ICE
• EAN: 4719331882488
• CPU socket: AMD Socket AM5
• Chipset: AMD B850
• Form factor: ATX (244 x 305 mm)
• Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, up to DDR5-8200 (O.C.), non-ECC
• Expansion slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x16 (x4 lanes)
• M.2 slots: 4x M.2 (M key): 1x PCIe 5.0, 3x PCIe 4.0
• SATA: 4x SATA III, RAID 0/1/10
• LAN: Realtek 5GbE
• Wireless: Wi-Fi 7 (Realtek RTL8922AE) with Bluetooth 5.4
• Audio: Realtek ALC1220 codec, 7.1 channels
• Rear USB: 1x USB-C 10 Gbit/s, 5x USB-A 10 Gbit/s, 2x USB-A 5 Gbit/s, 4x USB 2.0
• Video output: 1x DisplayPort (requires CPU with integrated graphics)
• Fan headers: 6x 4-pin PWM
• RGB headers: 1x RGB, 3x addressable RGB (RGB Fusion)
• Power connectors: 24-pin ATX + 8-pin ATX12V
• Colour: White
