Name: Asus PRIME A520M-A II/CSM AM4 Micro ATX Motherboard, AMD A520, DDR4, M.2
Brand: Asus
SKU: 100020035
Price: 99.60 EUR
Availability: InStock

Asus PRIME A520M-A II/CSM AM4 Micro ATX Motherboard, AMD A520, DDR4, M.2

€99.60

Delivery: 7-12 business days
Asus PRIME A520M-A II/CSM AM4 Micro ATX Motherboard, AMD A520, DDR4, M.2

Four DDR4 slots, up to 128 GB dual-channel
PCIe 4.0 x16 slot plus 1x M.2 and 4x SATA
HDMI, DisplayPort and VGA rear video outputs
Corporate Stable Model with ASUS Control Center Express

More information about warranty, delivery is in the FAQ ->
WARRANTY&FAQ DELIVERY
This product comes with a 1-year warranty provided by Xcellent PC.

In stock

SKU: 100020035 Category: AMD Motherboards Tags: A520,, Asus,, motherboard,, Ryzen Brand: Asus

Description
Additional information

✅

Product Overview

The Asus PRIME A520M-A II/CSM is a micro ATX motherboard built on the AMD A520 chipset for Socket AM4 processors. It has four DDR4 DIMM slots supporting up to 128 GB of dual-channel memory, one M.2 slot, four SATA 6 Gb/s ports and a PCIe 4.0 x16 slot. Video outputs for VGA, HDMI and DisplayPort are on the rear panel, which makes it practical for Ryzen CPUs with integrated graphics.

This board suits a compact, budget-focused AM4 build with a Ryzen 3 or Ryzen 5 processor, or an office and everyday PC. It includes Gigabit Ethernet, Realtek ALC897 audio, four USB 3.2 Gen 1 ports on the rear and Aura Sync RGB header support. As a Corporate Stable Model (CSM) it comes with ASUS Control Center Express and extended lifecycle support. Newer processors may need a BIOS update, and there is no onboard Wi-Fi.

Specification

Manufacturer: Asus
Model: PRIME A520M-A II/CSM
MPN: 90MB17H0-M0EAYC
EAN: 0195553135399
CPU Socket: AM4
Chipset: AMD A520
Form Factor: Micro ATX
Memory: 4x DDR4 DIMM, dual-channel, up to 128 GB
Memory Speeds: 2133 to 4866 MHz (3200 MHz and above via overclocking)
ECC Memory: Supported (unbuffered)
Expansion Slots: 1x PCIe x16 (PCIe 4.0 with supported CPUs), 2x PCIe 3.0 x1
Storage: 1x M.2 (PCIe), 4x SATA 6 Gb/s
RAID: 0, 1, 10
Rear Video Outputs: 1x HDMI, 1x DisplayPort, 1x VGA
Rear USB: 4x USB 3.2 Gen 1 Type-A, 2x USB 2.0
Networking: Realtek Gigabit Ethernet (no Wi-Fi)
Audio: Realtek ALC897
Fan and RGB Headers: 2x 4-pin PWM fan, 4x RGB LED header (Aura Sync)
Dimensions (W x D): 244 x 244 mm
