Product Overview

The Intel Core i5-13500T is a 14-core, 20-thread Raptor Lake desktop processor for the LGA 1700 socket. It combines 6 Performance cores (up to 4.6 GHz boost) with 8 Efficiency cores, and carries 24 MB of L3 cache. Its 35 W base TDP is the key difference from standard i5 models, making it suited to compact and low-power systems.

This CPU suits small-form-factor and quiet builds where heat and power draw matter, and it works with motherboards based on 600 and 700 series chipsets. It supports PCIe 5.0 and 4.0 as well as DDR5 and DDR4 memory, and includes Intel UHD Graphics 770 so you can run a PC without a separate graphics card. Note this is the tray version, which comes without a cooler, so you will need to buy one separately.

Specification

• Manufacturer: Intel
• Model: Core i5-13500T
• MPN: CM8071505092901
• CPU Series: Intel Core i5 (13th Gen, Raptor Lake)
• Socket: LGA 1700
• Cores / Threads: 14 cores / 20 threads
• Performance Cores: 6 cores, 12 threads
• Efficiency Cores: 8 cores, 8 threads
• Base Clock: 1.8 GHz
• Max Boost Clock (Performance cores): 4.6 GHz
• Max Boost Clock (Efficiency cores): 4.0 GHz
• L2 Cache: 20 MB
• L3 Cache: 24 MB
• TDP (Base Power): 35 W
• Maximum Turbo Power: 92 W
• Integrated Graphics: Intel UHD Graphics 770 (300 MHz base, 1500 MHz turbo)
• Max PCIe Version: 5.0
• Cooler Included: No (tray version)
