Product Overview

The Intel Core i5-13500 is a 14-core Raptor Lake desktop processor for the LGA1700 socket, combining 6 Performance cores and 8 Efficiency cores for 20 threads in total. The Performance cores run at a 2.5 GHz base clock with boosts up to 4.8 GHz, while the Efficiency cores run at 1.8 GHz base and up to 3.5 GHz boost. It has 24 MB of L3 cache and 20 MB of L2 cache.

This is a tray version, so it comes without a boxed cooler and you will need to supply your own. The 65 W base TDP (117 W maximum) and integrated Intel UHD Graphics 770 make it a good fit for a gaming or general-purpose PC that does not need a dedicated graphics card at first. It is compatible with motherboards based on 700-series and 600-series chipsets, supports PCIe 5.0 and 4.0, and works with both DDR5 and DDR4 memory depending on the board.

Specification

• Manufacturer: Intel
• Model: Core i5-13500
• MPN: CM8071505093101
• CPU Series: Intel Core i5 (13th generation, Raptor Lake)
• Socket: LGA1700
• Cores / Threads: 14 cores / 20 threads
• Performance Cores: 6 cores, 12 threads, 2.5 GHz base, 4.8 GHz boost
• Efficiency Cores: 8 cores, 8 threads, 1.8 GHz base, 3.5 GHz boost
• L2 Cache: 20 MB
• L3 Cache: 24 MB
• Base TDP: 65 W
• Maximum TDP: 117 W
• Integrated Graphics: Intel UHD Graphics 770 (300 MHz standard, 1500 MHz turbo)
• Max. PCIe Version: 5.0
• Memory Support: DDR5 and DDR4 (depending on motherboard)
• Cooler Included: No
• Packaging: Tray version
