Product Overview

The Samsung 990 EVO Plus 1 TB NVMe SSD is an internal M.2 2280 drive with V-NAND TLC memory and sequential speeds of up to 7,150 MB/s read and 6,300 MB/s write. It supports both PCIe 4.0 x4 and PCIe 5.0 x2 interfaces, and is rated for random performance of up to 850,000 IOPS read and 1,350,000 IOPS write.

This drive suits gaming PCs and general desktop builds that need fast storage in a standard M.2 2280 slot. Its 600 TB TBW rating and 1,500,000 hours MTBF cover long-term use, while 256-bit AES hardware encryption and the Samsung Magician software add data protection and drive monitoring. At 9 g and 2.38 mm thick, it is a compact drive with low power draw, using 4.3 W when reading and 0.06 W when idle.

Specification

• Manufacturer: Samsung
• Model: 990 EVO Plus
• MPN: MZ-V9S1T0BW
• EAN: 88060955756740
• Capacity: 1 TB
• Form factor: M.2 2280 (22 x 80 mm)
• Interface: PCIe 4.0 x4 / PCIe 5.0 x2, NVMe 2.0
• Sequential read: up to 7,150 MB/s
• Sequential write: up to 6,300 MB/s
• Random read (4KB): up to 850,000 IOPS
• Random write (4KB): up to 1,350,000 IOPS
• NAND type: V-NAND TLC
• Endurance (TBW): 600 TB
• MTBF: 1,500,000 hours
• Encryption: 256-bit AES hardware encryption
• Power consumption: 4.3 W read, 4.2 W write, 0.06 W idle
• Weight: 9 g
• Dimensions (W x H x D): 80.15 mm x 22.15 mm x 2.38 mm
