Product Overview

The Kingston DC2000B 960 GB NVMe SSD is an enterprise M.2 2280 drive using a PCIe 4.0 x4 interface and 112-layer 3D TLC NAND. It reads at up to 7,000 MB/s and writes at up to 1,300 MB/s, with 540,000 random read IOPS and 47,000 random write IOPS. What sets it apart from consumer M.2 drives is hardware-based power loss protection and a rated endurance of 700 TBW (0.4 DWPD).

The DC2000B is designed as an internal boot drive for high-volume rack-mount servers, freeing up front-loading drive bays, and for purpose-built systems that need a fast M.2 SSD with on-board power loss protection. It also suits high-speed application caching. An integrated aluminium heatsink broadens thermal compatibility, and the drive is rated for 0 to 70 °C operation, 2,000,000 hours MTBF and comes with a 5-year manufacturer warranty.

Specification

• Manufacturer: Kingston
• Model: DC2000B
• MPN: SEDC2000BM8/960G
• EAN: 0740617345186
• Capacity: 960 GB
• Form factor: M.2 2280 (22 x 80 mm)
• Interface: PCIe 4.0 x4, NVMe
• NAND type: 3D TLC (112-layer)
• Sequential read: up to 7,000 MB/s
• Sequential write: up to 1,300 MB/s
• Random read (4KB): 540,000 IOPS
• Random write (4KB): 47,000 IOPS
• Latency (read / write): 70 µs / 20 µs
• Endurance: 700 TBW (0.4 DWPD)
• Power loss protection: Hardware-based PLP
• MTBF: 2,000,000 hours
• Cooling: Aluminium heatsink
• Average power consumption (write): 7.36 W
• Operating temperature: 0 – 70 °C
• Weight: 11 g
• Manufacturer warranty: 5 years
