Product Overview

The Thermaltake Toughpower GF3 1200W is a 1200 W ATX power supply with 80 PLUS Gold certification and efficiency of up to 90 %. It follows the ATX12V 3.0 standard, is PCIe Gen 5 compliant and includes a 12VHPWR (12+4 pin) cable for modern graphics cards. The cables are fully modular, flat and black, with a low profile.

With a single +12V rail, a DC-DC design and Japanese 105°C capacitors, this unit suits high-end gaming builds with a power-hungry GPU. The 140 mm hydraulic-bearing fan runs semi-passively with the Smart Zero Fan feature, spinning down at low loads (0 dB(A) at 20% load, 28.4 dB(A) at 100%). It measures 150 x 86 x 160 mm and includes six protection circuits (OCP, OVP, UVP, OPP, SCP, OTP).

Specification

• Manufacturer: Thermaltake
• Model: Toughpower GF3 1200W
• MPN: PS-TPD-1200FNFAGE-4
• EAN: 4713227534147
• Power output: 1200 W
• Efficiency certification: 80 PLUS Gold (up to 90 %)
• Standard: ATX12V 3.0, PCIe Gen 5 compliant
• Form factor: ATX
• Modularity: Fully modular, flat black cables
• GPU power connectors: 1x 12+4 pin (12VHPWR), 4x 6+2 pin
• Other connectors: 1x 24-pin ATX, 1x 4+4-pin 12V, 1x 8-pin 12V, 12x SATA, 4x 5.25″ 4-pin
• Fan: 1x 140 mm, hydraulic bearing, semi-passive, temperature controlled
• Noise level: 0 dB(A) at 20% load, 8.7 dB(A) at 50%, 28.4 dB(A) at 100%
• Input voltage: 100-240 V, Active PFC
• Protections: OCP, OVP, UVP, OLP/OPP, SCP, OTP
• Dimensions (W x H x D): 150 x 86 x 160 mm
• Colour: Black
