Product Overview

The Thermaltake Smart W3 500W is a 500 W ATX power supply certified to the basic 80 PLUS standard and built to the ATX12V 3.1 specification. All 500 W is available on the single +12 V rail (41.67 A), with 100 W combined on the 3.3 V and 5 V rails, and active PFC keeps power delivery efficient.

This is an entry-level unit aimed at budget-conscious builders who want a dependable PSU for an office, home or basic gaming PC. It includes two 6+2-pin PCIe connectors for a single mid-range graphics card, four SATA connectors and four 5.25-inch Molex connectors for drives and peripherals. Protection covers OCP, OVP, UVP, OPP, SCP and OTP, and the standard ATX size (150 x 86 x 140 mm) fits most cases.

Specification

• Manufacturer: Thermaltake
• Model: Smart W3 500W
• MPN: PS-SPW-0500NNFAWE-1
• EAN: 4711475645363
• Power output: 500 W
• Form factor: ATX
• Standard: ATX12V 3.1
• Efficiency certification: 80 PLUS
• +12 V output: 500 W (41.67 A, single rail)
• +3.3 V / +5 V combined: 100 W (16 A each)
• Input voltage: 100-240 V
• Power factor correction: Active PFC
• Connectors: 1x 24-pin ATX, 1x 4+4-pin CPU, 2x 6+2-pin PCIe, 4x SATA, 4x 4-pin Molex
• Protections: OCP, OVP, UVP, OPP, SCP, OTP
• Power switch: Yes
• Dimensions (W x H x D): 150 x 86 x 140 mm
