Product Overview

The Asus PRO Q870M-C-CSM Intel Q870 motherboard is a micro-ATX business board for LGA 1851 processors, covering the Intel Core Ultra (Series 2) range. It offers four DDR5 slots for up to 256 GB of memory at speeds up to 6400 MHz, a PCIe 5.0 M.2 slot alongside a second PCIe 4.0 M.2 slot, and an Intel I219-LM Gigabit LAN controller. Intel vPro support is part of the package.

This board suits office, workstation-style and managed business PCs built around a Core Ultra processor, especially where manageability and long-term availability matter. Video output comes from HDMI and two DisplayPort connectors, which need a CPU with integrated graphics. Legacy PS/2 ports, optional serial, parallel and TPM headers and RAID 0, 1, 5 and 10 support round out the feature set. A BIOS update may be needed for the newest processors.

Specification

• Manufacturer: Asus
• Model: PRO Q870M-C-CSM
• MPN: 90MB1KEP-M0EAYC
• EAN: 4711387880586
• CPU socket: LGA 1851
• Chipset: Intel Q870
• Form factor: micro-ATX (244 x 244 mm)
• Supported processors: Intel Core Ultra 5/7/9 (Series 2, Arrow Lake)
• Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, non-ECC
• Memory speed: DDR5-6400 / 5200 / 4800 / 4400
• M.2 slots: 2x M.2 (M key): Slot 1 PCIe 5.0, Slot 2 PCIe 4.0
• SATA: 4x SATA III 6 Gb/s, RAID 0/1/5/10
• Expansion slots: 1x PCIe x16, 1x PCIe x16 (x4 lanes), 1x PCIe x1
• Video outputs: 1x HDMI, 2x DisplayPort (requires CPU with integrated graphics)
• Rear USB: 1x USB-C 10 Gbit/s, 2x USB-A 10 Gbit/s, 1x USB-A 5 Gbit/s, 2x USB 2.0
• Networking: Intel I219-LM Gigabit Ethernet (no Wi-Fi on board)
• Audio: Realtek 7.1 surround
• RGB: AURA Sync
• Weight: 550.6 g
• Dimensions (W x H x D): 244 x 50 x 244 mm
