Product Overview

The Kingston ValueRAM KSM32RD4/64HD 64 GB DDR4-3200 is a single 64 GB registered ECC DIMM built on 288-pin DDR4 technology. It is a 2Rx4 module with 8G x 72-bit organisation, made from thirty-six 4G x 4-bit FBGA components, and it runs at JEDEC-standard DDR4-3200 timings of 22-22-22 at 1.2 V.

Kingston lists this module as a component for servers, so it suits platforms that support registered ECC DDR4 rather than ordinary consumer desktop boards. Check your motherboard’s memory support before ordering. The SPD is programmed to the JEDEC profile, the 288-pin DIMM uses gold contact fingers, and the module is RoHS compliant. It measures 133.3 mm wide and 31.2 mm high.

Specification

• Manufacturer: Kingston
• Model: ValueRAM KSM32RD4/64HD
• MPN: KSM32RD4/64HD
• EAN: 0740617348200
• Capacity: 64 GB (1 x 64 GB)
• Memory type: DDR4 SDRAM
• Speed: DDR4-3200 (PC4-25600), 3200 MT/s
• Timings: CL22-22-22
• Error correction: ECC
• Buffering: Registered (with parity)
• Ranking: 2Rx4
• Module configuration: 8192M x 72
• Form factor: 288-pin DIMM
• Voltage: 1.2 V
• Colour: Black
• Operating temperature: 0 – 85 °C
• Width: 133.3 mm
• Height: 31.2 mm
