Product Overview

The Sapphire Radeon RX 9070 XT Nitro+ Phantom Link OC is a 16 GB GDDR6 graphics card built on AMD’s RDNA 4 architecture with 4096 stream processors and 64 Compute Units. It runs a game clock of 2520 MHz and an OC boost clock of up to 3060 MHz, with a 256-bit memory bus delivering 640 GB/s of bandwidth. Its power connector sits on the underside of the card.

This card is aimed at gamers building for 1440p and 4K, with support for FSR 4 with AI upscaling, hardware ray tracing, AMD Fluid Motion Frames and AV1 encode/decode. Connectivity is two DisplayPort 2.1b and two HDMI 2.1a outputs. It uses a single 16-pin (12VHPWR) connector, needs a PSU of at least 750 W and takes up 3.2 slots in a PCIe 5.0 x16 slot, so check case clearance for its 330.8 mm length.

Specification

• Manufacturer: Sapphire
• Model: Radeon RX 9070 XT Nitro+ Phantom Link OC
• MPN: 11348-08-20G
• EAN: 4895106297500
• GPU: AMD Radeon RX 9070 XT (RDNA 4)
• Stream processors: 4096
• Compute units: 64 (3rd Gen RT + 2nd Gen AI Accelerators)
• Game clock: 2520 MHz
• Boost clock (OC): 3060 MHz
• Memory: 16 GB GDDR6
• Memory interface: 256-bit
• Memory speed: 20 Gbps
• Memory bandwidth: 640 GB/s
• Outputs: 2x DisplayPort 2.1b, 2x HDMI 2.1a
• Power connector: 1x 16-pin (12VHPWR), on underside of card
• Average power consumption: 330 W
• Minimum PSU: 750 W
• Interface: PCIe 5.0 x16
• Slots occupied: 3.2
• Dimensions (W x H x D): 141.25 x 65.68 x 330.8 mm
• Colour: Silver
