Product Overview

The Intel Core i9-14900 processor is a 24-core, 32-thread Raptor Lake-S desktop CPU for the LGA 1700 socket. It combines 8 Performance cores that boost up to 5.8 GHz with 16 Efficiency cores boosting up to 4.3 GHz, backed by 32 MB of L2 cache and 36 MB of L3 cache. It has a 125 W base power rating, and the integrated Intel UHD Graphics 770 means a display output without a separate graphics card.

This is the tray version, supplied without a cooler, so you will need to fit your own CPU cooler capable of handling the 125 W base power and 253 W maximum turbo power. It works with motherboards based on the Intel 700 and 600 series chipsets, and supports PCIe 5.0 and 4.0 as well as DDR5 and DDR4 memory. It suits high-end gaming and multitasking builds where the Performance cores handle demanding workloads and the Efficiency cores take over at low load.

Specification

• Manufacturer: Intel
• Model: Core i9-14900
• MPN: CM8071504820609
• CPU Type: Intel Core i9 (Raptor Lake-S, 14th generation)
• Socket: LGA 1700
• Cores / Threads: 24 cores / 32 threads
• Performance Cores: 8 cores, 16 threads, 3.2 GHz base, up to 5.8 GHz boost
• Efficiency Cores: 16 cores, 16 threads, 2.0 GHz base, up to 4.3 GHz boost
• L2 Cache: 32 MB
• L3 Cache: 36 MB
• Integrated Graphics: Intel UHD Graphics 770 (300 MHz standard, 1500 MHz turbo)
• TDP: 125 W (253 W maximum)
• Max. PCIe Version: 5.0
• Memory Support: DDR5 and DDR4, ECC supported
• Chipset Compatibility: Intel 700 and 600 series
• Cooler: Not included (tray version)
